• (4) 12V aux pwr points
• (6) cup holders
• 1st/2nd row assist handles
• 1st/2nd row color-keyed carpeted floor mats
• 2nd row reclining 60/40 split bench seat-inc: dual recline, tip/slide
• 3rd row bench seat w/rollers
• Cargo net w/tie downs
• Cigarette lighter
• Cloth 40/20/40 split front bench seat w/lumbar
• Color-keyed floor carpeting
• Color-keyed sun visors-inc: illuminated vanity mirrors, secondary sun blade
• Electrochromic rearview mirror
• ETR AM/FM stereo w/compact disc/cassette
• Glove box
• Leather-wrapped tilt steering wheel w/speed control
• Manual front/rear air conditioning w/rear controls
• Overhead console
• Pwr door locks w/autolock
• Pwr windows
• Rear floor heat ducts
• Rear window defroster
• Remote keyless entry-inc: 2-transmitters, door keypad
• SecuriLock Passive anti-theft system
• Speed control
• Tilt steering column

• (4) 16" x 7.0" chrome steel wheels
• (5) LT265/75R16 all-terrain SBR OWL tires
• 2-speed transfer case w/Control Trac Shift-on-the-Fly
• 4-wheel anti-lock braking system
• 4-wheel drive
• 4.10 limited slip rear axle ratio
• 44 gallon fuel tank
• 78 amp/hr (750 CCA) battery
• 8,900# GVWR (3800 front/5240 rear), springs (3800 front/5240 rear), axles (5200 front/7000 rear)
• Class IV trailer towing pkg-inc: 7-wire harness, trailer brake wiring kit, towing guide
• Front stabilizer bar
• Full size spare tire w/steel wheel
• Pwr 4-wheel disc brakes
• Pwr steering
• Rear stabilizer bar

• (1) 3rd row child seat tether anchor
• (3) 2nd row child seat tether anchors
• 1st/2nd row safety belts w/adjustable D-rings
• 4-wheel anti-lock braking system
• Child-proof rear door locks
• Driver & front passenger airbags

5.4L (330) SOHC SEFI V8 "TRITON" ENGINE

• (STD)

• Limited Slip w/4.10 Axle Ratio
• GVWR: 8,900 lbs Payload Package
• AM/FM Stereo Dual Media Single CD w/Clock
• 4-Wheel Disc Brakes
• Speed-Sensitive Wipers
• Front beverage holders
• Variably intermittent wipers
• Tilt steering wheel
• Split folding rear seat
• Speed-sensing steering
• Speed control
• Remote keyless entry
• Rear window wiper
• Rear window defroster
• Rear seat center armrest
• Rear reading lights
• Rear anti-roll bar
• Power windows
• Power steering
• Power door mirrors
• Passenger vanity mirror
• Passenger door bin
• Panic alarm
• Leather steering wheel
• Illuminated entry
• Heated door mirrors
• Front reading lights
• Front anti-roll bar
• Dual front impact airbags
• Driver vanity mirror
• Driver door bin
• CD player
• Bumpers: chrome
• AM/FM radio
• ABS brakes
• Tachometer
• Cassette
• Air Conditioning
• 6 Speakers

• Brakes
• Brake ABS System: 4-Wheel
• Brake Type: Power
• Disc - Front (Yes or ): Yes
• Disc - Rear (Yes or ): Yes
• Front Brake Rotor Diam x Thickness (in): 12.13 x
• Rear Brake Rotor Diam x Thickness (in): 13.20 x
• Cargo Area Dimensions
• Cargo Area Length : Floor to Console (in)
• Cargo Area Length : Floor to Seat 1 (in)
• Cargo Area Length : Floor to Seat 2 (in)
• Cargo Area Length : Floor to Seat 3 (in)
• Cargo Area Length : Floor to Seat 4 (in)
• Cargo Area Width : Beltline (in)
• Cargo Box Width : Wheelhousings (in)
• Cargo Volume to Seat 1 (ft³): 146.4
• Cargo Volume to Seat 2 (ft³): 100.7
• Cargo Volume to Seat 3 (ft³): 48.0
• Cooling System
• Total Cooling System Capacity (qts): 26.4
• Electrical
• Cold Cranking Amps : 0° F (2nd)
• Cold Cranking Amps : 0° F (Primary)
• Maximum Alternator Capacity (amps): 130
• Maximum Alternator Watts: 1950
• Exterior Dimensions
• Ground Clearance, Rear (in): 8.1
• Height, Overall (in): 80.2
• Length, Overall w/rear bumper (in): 226.7
• Overhang, Front (in): 37.4
• Overhang, Rear w/bumper (in): 52.3
• Rear Door Opening Height (in): 38.1
• Rear Door Opening Width (in): 55.8
• Wheelbase (in): 137.1
• Width, Max w/o mirrors (in): 79.9
• Frame
• Frame Type: Ladder w/BlockerBeam
• Fuel Tank
• Fuel Tank Capacity, Approx (gal): 44
• Fuel Tank Location: Aft-of-axle
• Interior Dimensions
• Front Head Room (in): 41.0
• Front Hip Room (in): 67.5
• Front Leg Room (in): 42.3
• Front Shoulder Room (in): 68.3
• Passenger Capacity: 9
• Second Head Room (in): 41.1
• Second Hip Room (in): 66.9
• Second Leg Room (in): 40.5
• Second Shoulder Room (in): 67.0
• Third Head Room (in): 38.6
• Third Hip Room (in): 52.5
• Third Leg Room (in): 39.0
• Third Shoulder Room (in): 64.9
• Steering
• Steering Ratio (:1), On Center: 17.0
• Steering Type: Power
• Turning Diameter - Curb to Curb (ft): 50.4
• Summary
• Body Code: 137" WB
• Body Style: 4 door
• Vehicle Name: Ford Excursion
• Suspension
• Axle Capacity - Front (lbs): 5200
• Axle Capacity - Rear (lbs): 7000
• Axle Ratio (:1) - Front: 4.10
• Axle Ratio (:1) - Rear: 4.10
• Axle Type - Front: Dana 50 Monobeam
• Axle Type - Rear: Ford Std & Lim Slip
• Shock Absorber Diameter - Front (mm): 35
• Shock Absorber Diameter - Rear (mm): 35
• Spring Capacity - Front (lbs): 3800
• Spring Capacity - Rear (lbs): 5240
• Stabilizer Bar Diameter - Front (in): 1.42
• Suspension Type - Front: Single-Stage Leaf
• Suspension Type - Rear: Single-Stage Leaf
• Tires
• Front Tire Capacity (lbs): 3000
• Front Tire Order Code: T4T
• Front Tire Size: LT265/75R16D
• Rear Tire Capacity (lbs): 3000
• Rear Tire Order Code: T4T
• Rear Tire Size: LT265/75R16D
• Revolutions/Mile : 45 mph - Front
• Revolutions/Mile : 45 mph - Rear
• Revolutions/Mile : 45 mph - Spare
• Spare Tire Capacity (lbs): 3000
• Spare Tire Order Code: T4T
• Spare Tire Size: LT265/75R16D
• Trailering
• Dead Weight Hitch - Max Tongue Wt. (lbs): 500
• Dead Weight Hitch - Max Trailer Wt. (lbs): 5000
• Fifth Wheel Hitch - Max Tongue Wt. (lbs): N/A
• Fifth Wheel Hitch - Max Trailer Wt. (lbs): N/A
• Wt Distributing Hitch - Max Tongue Wt. (lbs): 720
• Wt Distributing Hitch - Max Trailer Wt. (lbs): 7200
• Vehicle
• Rear Door Type: Tri-Panel
• Weight Information
• Curb Weight - Front (lbs): 3524
• Curb Weight - Rear (lbs): 3563
• Gross Axle Wt Rating - Front (lbs): 3800
• Gross Axle Wt Rating - Rear (lbs): 5240
• Gross Combined Wt Rating (lbs): 14500
• Gross Vehicle Weight Rating Cap (lbs): 8900
• Wheels
• Front Wheel Material: Chrome
• Front Wheel Size (in): 16 x 7.0
• Rear Wheel Material: Chrome
• Rear Wheel Size (in): 16 x 7.0
• Spare Wheel Material: Steel
• Spare Wheel Size (in): 16 x 7.0
